Walk in steps (required) allow for much easier entry and exit
Coronado above ground pools are best described as Bigger, Better, Stronger, Longer Lasting pools.
54" Wall w True 8€ Resin Top Rails with 7€ Uprights
3 Year Filter System warranty (Industry Best)
8 Year Full + 22 Year Pro-Rated warranty (Industry Best)
Coronado above ground pools are best described as Bigger, Better,
Stronger, Longer Lasting above ground pools. The CaliMar® brand,
Coronado model 54" wall above ground pools have Bigger True 8" Top Rails made with Better. Resin materials make this pool Stronger and is assured to last Longer with it's un-matched 8 Year Full-100% warranty plus an additional 22 year Pro-Rated Warranty.
Made with the exact same materials and same exacting standards as
Doughboy pools are known for, the CaliMar® pools are also made. We’ve
taken the best of the best of what we know to work hand in hand with
H.I.I. to architect and design a series of above ground pools that break
the mold and set new standards in the pool industry.
The Coronado above ground pool models all are stronger empty than many other above ground pools are when they’re full. The top rails are a true 8” across measuring from edge to edge. Other manufacturers that claim to be 8” wide are measuring around the circumferance of the top rail. If the Coronado top rails were measured using the same method, they would be 12” wide.
Cross Section of Resin Top Rail
Liners
The liners that come standard in the Coronado models are True 15 mil liners, not gauge. Gauge is a matter of subjection and any manufacturer can set their gauge to whatever suits their marketing needs. Mil is an exact international precise measurement for measuring thickness. Measurement is done with a micrometer and all of the liners packaged with the CaliMar® pools are a True 15 Mil Thickness. The liners are about 20% heavier than other liners on the market because of the true nature of the virgin vinyl material and zero use of plasticizers and fillers. Due to the superior strength and integrity of these liners we offer a Lifetime 100% Warranty against seam separations. Upgrade available to 20 mil.
Bottom Rails
Engineered with True-Fold design and thicker Premium Steel with a high end coating all Coronado above ground pools have a 100% Lifetime Warranty.
Component Connection Points
All connection points on Coronado pools are precision punched holes so there is only one way the pool can be assembled, making assembly quicker and easier. Other above ground pools have “oval” shaped holes which allow too much variance causing imperfect fit and weakens the strength of the pool.
Walls
Made from heavier copper bearing steel than industry standards making them 30-60 lbs heavier than other manufacturer models pools. Zinc clad hot-dipped glavanized steel walls receive several protective coatings and a specifically designed epoxy coating providing the
best defense against corrosion and condensation. Industry’s thickest corrugation offers industry’s greatest strength and flexibility. Layers of wall protection shown below
Vertical Uprights
Coronado's steel thickness is 25% thicker than the competition providing extra stability and strength to the pool wall.
Skimmer
Large skim surface area removes surface debris faster than any other skimmer on the market. The tall mouth construction allows for greater pool water height fluctuations with a basket twice the size of many competitors.
Vacuum port built into the lower face of the skimmer makes connection of vacuum hose or automatic pool vacuum much easier. Includes skimmer winterizing components and “skimmer door”.
Coronado above ground pools ship from the Memphis, TN area, home of Doughboy pools.
Express Shipping
In-Stock Orders ship within 48 - 72 working hours, delivery approximately 3 business days after shipment, not including the day the pool ships
Unparalleled shipping capabilities in the pool industry
Centrally located less than 75 miles from Memphis, TN.
(Distribution capital of the US)
Committed to superior shipping services
Can I install the pool myself?
Yes. If you are relatively handy and can follow written directions then putting an above ground pool together should not be out of the question. Of course if you’ve any questions along the way, you are more than welcome to give us a call and we’ll
‘walk you through it’.
Round CaliMar above ground pool installation video:
Oval CaliMar above ground pool installation video:
Pool Size
Pool Shape
Gallons 52" Walls
Gallons 54" Walls
Yards of Sand
Number of Uprights
Number of Top Rails
16'
Round
5,068
5,260
1-1/2
11
10
18'
Round
7,298
7,575
1-1/2 - 2
13
12
21'
Round
9,930
10,307
2-1/2 - 3
15
14
24'
Round
12,974
13,467
3 - 3-1/2
16
15
27'
Round
16,420
17,044
3-1/2 - 4
19
18
30'
Round
20,710
21,497
5
21
20
33'
Round
27,500
28,545
6
22
21
12' x 20'
Oval
8,900
9,238
1-1/2 - 2
14
13
12' x 24'
Oval
9,200
9550
1-1/2 - 2
16
15
16' x 24'
Oval
11,000
11,418
2-1/2
16
15
16' x 28'
Oval
11,450
11,885
3 - 3-1/2
18
17
16' x 32'
Oval
14,952
15,521
3-1/2 - 4
20
19
18' x 33'
Oval
15,041
15,613
4-1/2 - 5
22
21
Gallons and Yards of Sand Needed under the liner are approximates.
Items Included in the Package
Warranty
6 CaliMar Above Ground Pools with an 8 Year Full + 22 Year Pro-Rated Warranty against manufacture defects.
Free Shipping
